Schneider Electric E32_1_2AR_WE_G2 1-way Switch - S-Classic
Schneider Electric E32_1_2AR_WE_G2 1-way Switch - S-Classic
Brand: | SCHNEIDER ELECTRIC |
Model: | E32_1_2AR_WE_G2 |
Specifications
Please select at least one specification below.
Width
87 mm
Material
Plate: PC (polycarbonate), white
Dolly: PC (polycarbonate), white
Base: PA66, black
Depth
28.9 mm
Standards
BS EN 60669-1
SS 227-1
MS IEC 60669-1
GB 16915.1
IEC 60669-1
Height
87 mm
Relative humidity
0…95 %
Number of gangs
2 gangs
Device mounting
Flush
Surface
Switch function
1-way
Rated Current
10 AX at 250 V AC
Control type
Rocker
This spec is not available in the specification table.
Product or component type
Switch
This spec is not available in the specification table.
Range
S-Classic
This spec is not available in the specification table.
Ambient air temperature for operation
-5…40 °C
This spec is not available in the specification table.
Actuator
Rocker
This spec is not available in the specification table.
Embedding depth
12.3 mm
This spec is not available in the specification table.
Number of terminals
2
This spec is not available in the specification table.
Switch application
Lighting
This spec is not available in the specification table.
Product Description
US $ 5.35
