Rs Pro 476577 Pcb Mount Latching Power Relay, 12V Dc Coil, 50A Switching Current, Spst
Rs Pro 476577 Pcb Mount Latching Power Relay, 12V Dc Coil, 50A Switching Current, Spst
Brand:
RS Pro
Model:
476577
Technical Data Sheets
Specifications
infotip-icon
View other Power Relay dimensions or variations
Please select at least one specification below.
Length
39 mm
Application
Power
Mounting Type
PCB Mount
Depth
15 mm
Height
30.2 mm
Contact Material
Silver Alloy
Contact Configuration
SPST
Coil Voltage
12 V dc
Standards Met
RoHS Compliant
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+70°C
Terminal Type
Through Hole
Maximum Switching Voltage AC
440 V ac
Coil Power
3 W
Coil Resistance
48 Ohm
Isolation Coil To Contact
4 kV ac
Switching Current
50 A
Maximum Switching Power AC
12.5 kVA
Life
1000000 (Mechanical) cycles
This spec is not available in the specification table.
Latching
Yes
This spec is not available in the specification table.
