Rs Pro 1815117 1000 Microfarad Aluminium Electrolytic Capacitor 25V Dc, Radial, Through Hole

View Brand

Rs Pro 1815117 1000 Microfarad Aluminium Electrolytic Capacitor 25V Dc, Radial, Through Hole

Brand:	RS Pro
Model:	1815117

Technical Data Sheets

RS PRO Datasheet

Specifications

View other Aluminium Capacitors dimensions or variations

Voltage

25 VDC

Mounting Type

Radial, Through Hole

Dimensions

13 Dia. x 21 mm

Capacitance

1000 µF

Lead Pitch

5 mm

Lifetime

1000h

Ripple Current

1.65 A

Leakage Current

2 µA

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+105°C

Dissipation Factor

14%

Tolerance

±20%

Product Description

US $ 111.75

Quantity:

MOQ of 250 EA

Bundle of 250 EA

This item is sold by

SG-4570630354
