Multicomp Pro MCUMR25V336M6.3X5 Cap, 33µF, 25V, 20% Electrolytic Capacitor

View Brand

Multicomp Pro MCUMR25V336M6.3X5 Cap, 33µF, 25V, 20% Electrolytic Capacitor

Brand:	MULTICOMP PRO
Model:	MCUMR25V336M6.3X5

Technical Data Sheets

Technical Data Sheet (236.36KB) EN

Specifications

View other Aluminium Capacitors dimensions or variations

Voltage

25 V

Dimensions

6.3 (Dia.) x 5 mm

Capacitance

33 µF

Lifetime

1000 hours @ 85°C

Ripple Current

52 mA

Leakage Current

8.25 µA

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

85°C

Tolerance

± 20%

Product Description

US $ 0.09

Quantity:

This item is sold by

SG-7425082168
