Features
- Accuracy to 0.01% of reading
- Small and rugged handheld design
- Measure, source, or simulate loop current
- Measure DC volts
- Simultaneously mA and % span display
- Switch functionality
- Selectable ramp and step functions
- Easy to read display and user interface
- HART 250Ω resistor in series with 24V loop


Voltage Limit: 30V between terminals or between terminals and ground
Measurement Functions: Auto step, auto ramp, span step
Display: VA LCD display. 2.04 x 2.04 in (52 x 52mm)
Loop Power: 24V
Over-Voltage Protection: 30V DC (240V AC)
Overload Current Protection: 33 mA DC
Storage Temperature: -20C to 7oC
Working Environment: -10 to 5oC, 95%RH
Working Altitude: <3, 000 m
Vibration/Shock: Random 2G 5 to 500Hz - 1 meter drop
Power: One 9V alkaline battery (ANSI/NEDA 1604A or IEC) / DC9V optional adapter available
Battery Life (typical): Output mode: 18 hours (12 mA/500Ω) / Measure mode: 50 hours
Size(LxWxH) : 163 x 83 x 41mm
Weight : 350g
