TZ-BT05
Bluetooth 4.0 Temperature Data Logger

TZ-BT05 is a low power consumption Bluetooth data logger, using the latest Bluetooth 4.0 technology, Nordic N51822 chip development, and design, through Bluetooth 4.1 collecting the surrounding environment temperature, and recording and preservation of historical data can store up to 12,000 pieces of temperature data. Bluetooth 4.1 can be downloaded over the phone APP configuration tools, to achieve full stage real-time temperature recording. It has a small size, is lightweight, is easy to carry, has high accuracy and other characteristics, widely used in various other areas of refrigerated storage and transport, archives, experimental (test) rooms, museums, and other temperature monitoring.

Features:

• A real-time measure of temperature
• High accuracy and stability
• Bluetooth 4.1 (Nordic Chip)
• Long-distance wireless transfer
• Built-in highly sensitive temperature sensor
• Can store 12,000 pieces of temperature data
• History report can be sent to the specified email
• LED light indicating the different status
• Can choose time to query data, every time query of data, the stored data can be saved in history
• Can set normal storage temperature data interval and alarm storage temperature data interval

Application:

• Cold chain logistics
• Archives
• Labs
• Factory workshop
• Museum
• Building temperature and humidity control
• Medical environment

Specification:

• Signal transmission frequency: 2.400-2.4835GHz
• Protocol standard: Bluetooth 4.1
• Modulation mode: GFSK
• Transmission interval: 10 Sec, adjustable
• Internal battery: CR2450, 620mAh / 3V
• Output Power: -4dBm, adjustable
• Communication rate: 1Mbps
• Transmission distance: 55 meters, adjustable
• Storage: Can store 12,000 temperature data
• Battery life: 3 years (depends on the working mode)
• Temperature detection range: -25℃~+60℃
• Temperature detection accuracy: ±0.5℃ (-20℃~+40℃), ±1℃(others)
• Temperature Operation range: -25℃~+60℃
• IP rating: IP54
• Net weight: 25g
• Outline size: 50mm*35mm*15mm

Mobile APP

• Download the "Humiture Recorder" mobile application from Android App Store.
• It provides temperature monitoring.
• The BT05 through the Bluetooth of the mobile device is able to do setting, data transmission, recording, synchronization, and send PDF reports by email.
