Specifications

Connector(s)

Connector Type(s)
7 - USB Type-A (9 pin, 5 Gbps)
1 - USB 3.2 Type-B (9 pin, Gen 1, 5Gbps)
1 - Terminal Block (2 Wire)

Hardware
USB-C Device Port(s)
No
USB-C Host Connection
No
Fast-Charge Port(s)
Yes
Ports
7
Interface
USB 3.2 Gen 1 (5Gbps)
Bus Type
USB 3.2 Gen 1 (5Gbps)
Industry Standards
USB Battery Charging Specification Rev. 1.2
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Chipset ID
Genesys Logic - GL3520

Indicators

LED Indicators
1 - Power (Green)

Performance

Maximum Data Transfer Rate
5 Gbps (USB 3.2 Gen 1)
Type and Rate
USB 3.2 Gen 1 - 5 Gbit/s
ESD Protection
+/-15kV (Air)
+/-8kV (Contact)
Surge Protection
350W on the DFP and UFP
MTBF
126,106 Hours

Performance

Maximum Data Transfer Rate
5 Gbps (USB 3.2 Gen 1)
Type and Rate
USB 3.2 Gen 1 - 5 Gbit/s
ESD Protection
+/-15kV (Air)
+/-8kV (Contact)
Surge Protection
350W on the DFP and UFP
MTBF
126,106 Hours
