Specifications

Connector(s)

Connector Type(s)
10 - USB Type-A (9 pin, 5 Gbps)
1 - USB 3.2 Type-B (9 pin, Gen 1, 5Gbps)
1 - Terminal Block (2 Wire)

Hardware

USB-C Device Port(s)
No
USB-C Host Connection
No
Fast-Charge Port(s)
Yes
Ports
10
Interface
USB 3.2 Gen 1 (5Gbps)
Bus Type
USB 3.2 Gen 1 (5Gbps)
Industry Standards
USB Battery Charging Specification Rev. 1.2
USB 3.0 - Backward compatible with USB 2.0/1.1
Chipset ID
Genesys Logic - GL3522

Indicators

LED Indicators
1 - Power (Green)

Power

Power Source
Terminal Block
Input Voltage
7 ~ 24 DC
Output Voltage
7 ~ 24 DC

Special Notes / Requirements

System and Cable Requirements
Host computer with an available USB 3.0 port
Note
This product is intended for use with terminal block power only – Standard AC adapter not available

If connected to a USB 2.0 host port, performance may be limited
