Samcom Electronic - Emergency Light Surface Mount Wide Angle
Samcom Electronic - Emergency Light Surface Mount Wide Angle
Brand:
SAMCOM
Model:
ETL 201P-LED
Technical Data Sheets
Product Description

Input Current : 230Vac 50/60Hz ± 10% or 115Vac 50/60Hz ± 10%

Battery : 2.4V 2.5Ah ( 2 hour duration) /4.5Ah ( >3 hour duration)

High temp Nickel Cadmium cells.

Lamp Used : 2 x >1.8w SMT NICHIA White LED

Minimum Rated Period : about 2 hrs

Mode : Non-Maintained ( Light up when electrical breakdown)

Operation Temp : ta 40 °C

Power Consumption : < 1.4W

Charge Monitor : Super bright green LED 5mm Ø

Recharge Period : 16 ~ 24 hrs

Electromagnetic Field : 8.7m gause @ 0.1m

Charger : Hybrid controlled charger

Protection : Auto switching to prevent battery over discharge.

Built-in incoming AC fuse and Battery DC fuse.

Tropical climate protection coating on hybrid circuit

Construction : Mounted Fire Retardant ABS housing

20mm Ø K/O hole. Fire retardant ABS lamp head

Dimension : 305mm(L) x 95mm(W) x 136mm(H)

Packing : One unit per carton

Weight : 1.9kg (Net) / 2.0kg (Gross)

Carton/Dimension : Double wall corrugated / 315mm(L) x 100mm(W) x 145mm(H)

Compliance : SS563-1:2000, SS563-2,2010/A1-2013,

SSIEC60598-2-22:2016, SSIEC60598:Part 1:2016,

PSB Test approved product.

Warranty : 1 Year ( Local carry-in )

One Stop Solution. (Sales and Project Quote) : +65-82001069 ( Vincent Cheng Chye Sheng )

Office contact : +65-67441100 Helpdesk

S$ 48.00
(exc. GST)
S$ 52.32
(inc. GST)
UnitsDiscountUnit Price
1 ~ 4-S$ 48.00
5 ~ 195% OFFS$ 45.60
20++10% OFFS$ 43.20
