Chint, 3 Poles, Nxc Contactor
Brand: | CHINT |
Model: | 3bf1660b57 |
Technical Data Sheets
Product Description
CHINT, 3 Poles, NXC AC Contactor
Miniature Circuit Breaker (MCB)
Specification:
- Rated Operation Current Ie : 6A ~630A
- Rated Operation Voltage Ue: 220V~690V
- Number of poles: 3P (Three Poles)
- Built-in Auxiliary Contact: 1NO & 1 NC
- Mechanical endurance: 120 000 cycles
- Compliant Standards: IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 60947-5-1
Available Rated Current:
- NXC-06, 3 Poles, 2.2kW, Max Operation Current: 6A
- NXC-09, 3 Poles, 4.0kW Max Operation Current: 9A
- NXC-12, 3 Poles, 5.5kW Max Operation Current: 12A
- NXC-18, 3 Poles, 7.5kW Max Operation Current: 18A
- NXC-25, 3 Poles, 11.0kW Max Operation Current: 25A
- NXC-32, 3 Poles, 15.0kW Max Operation Current: 32A
- NXC-40, 3 Poles, 18.5kW Max Operation Current: 40A
- NXC-50, 3 Poles, 22.0kW Max Operation Current: 50A
- NXC-65, 3 Poles, 30.0kW Max Operation Current: 65A
- NXC-85, 3 Poles, 37.0kW Max Operation Current: 85A
- NXC-100, 3 Poles, 45.0kW Max Operation Current: 100A
S$ 12.00 – S$ 100.32
(exc. GST)
S$ 13.08 - S$ 109.35
(inc. GST)
