Schneider Electric RXM3AB2JD Pasang Relai Daya, Kumparan Dc 12V, Arus Pengalih 10A, 3PDT
Schneider Electric RXM3AB2JD Pasang Relai Daya, Kumparan Dc 12V, Arus Pengalih 10A, 3PDT
Specifications
infotip-icon
View other Power Relay dimensions or variations
Please select at least one specification below.
Length
21 mm
Mounting Type
Plug In
Depth
47.7 mm
Height
27 mm
Contact Material
Silver Alloy
Contact Configuration
3PDT
Coil Voltage
12V dc
Standards Met
CE, CSA, EN/IEC, GOST, Lloyd's, REACH, RoHS Compliant, UL
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+55°C
Terminal Type
Plug In
Maximum Switching Voltage AC
250 V
Coil Power
900 mW
Coil Resistance
160 Ω
Maximum Switching Power DC
280 W
Switching Current
10 A
Maximum Switching Power AC
2.5 kVA
Number of Poles
3
This spec is not available in the specification table.
Life
100000 cycles
This spec is not available in the specification table.
Latching
No
This spec is not available in the specification table.
Series Name
Harmony Relay RXM
This spec is not available in the specification table.
Better World Product
Yes
This spec is not available in the specification table.
Better World Verification
Green Premium
This spec is not available in the specification table.
