Rs Pro 1845582 Sensor Kedekatan Gaya Barel Kapasitif, Deteksi M12 X 1, 2 Mm, Output Npn, 10 - 30 V Dc, IP67

View Brand

Rs Pro 1845582 Sensor Kedekatan Gaya Barel Kapasitif, Deteksi M12 X 1, 2 Mm, Output Npn, 10 - 30 V Dc, IP67

Merek:	RS Pro
Model:	1845582

Lembar Data Teknis

RS PRO Datasheet CR-12JL4---10K

RS PRO Factory Automation Sensors Guide

Specifications

View other Proximity Sensors dimensions or variations

Length

52 mm

Thread Size

M12 x 1

Body Style

Barrel

Supply Voltage

10 → 30 V dc

IP Rating

IP67

Maximum Operating Temperature

+55°C

Terminal Type

Cable

Maximum DC Voltage

30 V

Switching Frequency

50 Hz

Housing Material

PBT

Detection Range

2 mm

Output Type

NPN

Switching Current

15 mA

Sensor Technology

Capacitive

Deskripsi Produk

Rp 1.033.946
