Rs Pro 1964256 Green 0.5 Mm² Hook up Wire, 20 Awg, 16/0.2 Mm, 100m, Pvc Insulation (1 Reel of 100)

View Brand

Rs Pro 1964256 Green 0.5 Mm² Hook up Wire, 20 Awg, 16/0.2 Mm, 100m, Pvc Insulation (1 Reel of 100)

Brand:	RS Pro
Model:	1964256

Technical Data Sheets

RS PRO Datasheet

Cable Selection Guide

RS PRO Wiring and Connectivity Selection Guide 2021

Specifications

View other Electrical Wire dimensions or variations

Length

100 m

Current Rating

3 A

Voltage Rating

1 kV ac

Sheath Colour

Green

Insulation Material

PVC

American Wire Gauge

20 AWG

Minimum Operating Temperature

-15°C

Maximum Operating Temperature

+85°C

Outer Diameter

1.65 mm

Conductor Material

Annealed Tinned Copper

Core Strands

16/0.2 mm

Cable Type

Single Core

Cable Shape

Single Core

Wire Style

BS4808

Insulation Wall Thickness

0.3 mm

Product Description
