Specifications
Please select at least one specification below.
Bearing Type
Angular Contact Ball (Single Row)
Bore Diameter
100 mm
Outside Diameter
150 mm
Width
24 mm
Bearing Material
SUJ2 Equiv.
Measurement System
Metric System
This spec is not available in the specification table.
Weight
1370 g
This spec is not available in the specification table.
Environment Specification
Standard
This spec is not available in the specification table.
Load Direction
Radial / Thrust Load, Axial
This spec is not available in the specification table.
Basic Load Rating Cr (Dynamic)
68400 N
This spec is not available in the specification table.
Allowable Rotational Speed [rpm]
4700 rpm
This spec is not available in the specification table.
Precision (JIS)
Class 5
This spec is not available in the specification table.
Outer Ring Type
Flat
This spec is not available in the specification table.
Number of Raceway Ring Rows
Single Row
This spec is not available in the specification table.
Rolling Element Material
[Steel] SUJ2 Equiv.
This spec is not available in the specification table.
Basic Load Rating Cor (Static) [N]
70600 N
This spec is not available in the specification table.
Product Description
₱ 2,956
| Units | Discount | Unit Price |
|---|---|---|
| 1 | - | ₱ 2,956 |
Quantity:
EA
Stock:
9 EA in stock
