Schneider Electric SSL1A12JD Harmony Relay Series Solid State Relay, 2 a Load, Pcb Mount, 280 V Ac Load, 12 V Dc Control
Schneider Electric SSL1A12JD Harmony Relay Series Solid State Relay, 2 a Load, Pcb Mount, 280 V Ac Load, 12 V Dc Control
Brand: | SCHNEIDER ELECTRIC |
Model: | SSL1A12JD |
Specifications
Please select at least one specification below.
Series
Harmony Relay
Mounting Type
PCB Mount
Length
28 mm
Depth
5 mm
Height
15 mm
Operating Temperature Range
-20 → +80°C
Standards Met
CE, CSA, UL
Maximum Load Current
2 A
Maximum Load Voltage
280 V ac
Minimum Load Voltage
24 V ac
Minimum Control Voltage
3 V dc
Maximum Control Voltage
12 V dc
Switching Type
AC
Control Voltage Range
3 → 12 V dc
Minimum Load Current
0.07 A
Better World Product
Yes
This spec is not available in the specification table.
Better World Verification
Green Premium
This spec is not available in the specification table.
Number of Poles
1
This spec is not available in the specification table.
Dimensions
28 x 5 x 15mm
This spec is not available in the specification table.
Contact Configuration
SPST
This spec is not available in the specification table.
Special Features
Built-In Diode Protection Circuit & LED Indicator, Mounted on Universal AC/DC Sockets, Slim Interface SSL Relays with PCB Terminals
This spec is not available in the specification table.
Terminal Type
PCB Pin
This spec is not available in the specification table.
Capacitance
1.5pF
This spec is not available in the specification table.
Relay Type
Single Phase
This spec is not available in the specification table.
Load Voltage Range
24 → 280V ac
This spec is not available in the specification table.
Off State Leakage Current
4 mA
This spec is not available in the specification table.
Output Device
SCR
This spec is not available in the specification table.
Maximum Turn On Time
1/2 cycle
This spec is not available in the specification table.
Product Description
RM 98.08
Quantity:
EA
