Schneider Electric RSB1A120U7 Plug in Power Relay, 240V Ac Coil, 12A Switching Current, Spdt
Schneider Electric RSB1A120U7 Plug in Power Relay, 240V Ac Coil, 12A Switching Current, Spdt
Brand: | SCHNEIDER ELECTRIC |
Model: | RSB1A120U7 |
Specifications
Please select at least one specification below.
Length
29 mm
Application
Power
Mounting Type
Plug In
Depth
12.5 mm
Height
15.7 mm
Contact Material
Silver Alloy
Contact Configuration
SPDT
Coil Voltage
240V ac
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+70°C
Terminal Type
Plug In
Maximum Switching Voltage AC
400 V
Maximum Switching Voltage DC
300 V dc
Coil Power
750 mW
Coil Resistance
42500 Ω
Isolation Coil To Contact
5 kV ac
Switching Current
12 A
Maximum Switching Power AC
3 kVA
Number of Poles
1
This spec is not available in the specification table.
Life
100000 (Electrical) cycles, 30000000 (Mechanical) cycles
This spec is not available in the specification table.
Latching
No
This spec is not available in the specification table.
Series Name
Harmony Relay RSB
This spec is not available in the specification table.
Product Description
RM 986.34
Quantity:
EA
MOQ of 10 EA
Bundle of 10 EA
