Schneider Electric A9F77232 Acti 9 iC60N Mcb, 2P, 32A Curve C, 400V Ac, 12 → 144V Dc, 6 Ka Breaking Capacity

View Brand

Schneider Electric A9F77232 Acti 9 iC60N Mcb, 2P, 32A Curve C, 400V Ac, 12 → 144V Dc, 6 Ka Breaking Capacity

Brand:	SCHNEIDER ELECTRIC
Model:	A9F77232

Specifications

View other Miniature Circuit Breakers - MCBs dimensions or variations

Range

Acti 9

Poles Description

[In] Rated Current

32 A

Breaking Capacity

6 kA

Width

36 mm

Mounting Support

DIN Rail Mount

Series Name

iC60N

Tripping Characteristics

Type C

Circuit Breaker Type

MCB

Better World Product

Yes

Better World Verification

Green Premium

Rated AC Voltage

400 V, 440 V, 100 → 130 V, 12 → 60 V, 220 → 240 V, 380 → 415 V

Rated DC Voltage

12 → 144 V

Product Description

RM 474.19

Quantity:

This item is sold by

SG-4570630354
