Misumi C-JPBB2-3 Tapered - Large Head Locating Pins
View Brand
Misumi C-JPBB2-3 Tapered - Large Head Locating Pins
Brand:
MISUMI
Model:
C-JPBB2-3
Specifications
View other
Locating Pins
dimensions or variations
Please select at least one specification below.
Find Selected Specs
Type
Locating Pin
Steel Type
SUJ2 Equivalent
Insertion Guide Tip Shape
Round
Basic Shape
Large Head
Surface Treatment
Not Provided
This spec is not available in the specification table.
Locating Side Outer Dia.
3
mm
This spec is not available in the specification table.
Mounting Side Outer Dia.
2
mm
This spec is not available in the specification table.
Locating Side O.D. Tolerance
-0.01/-0.02
This spec is not available in the specification table.
Mounting Side Shape
Straight (Press-Fit)
This spec is not available in the specification table.
Heat Treatment
Directly Quenching
This spec is not available in the specification table.
Insertion Guide Tip Type
Tapered
This spec is not available in the specification table.
Mounting Side Tolerance
m6
This spec is not available in the specification table.
Dimension Configurable Type
P Fixed
This spec is not available in the specification table.
Product Description
Misumi C-JPBB2-3 Tapered - Large Head Locating Pins
Basic Shape: Large Head
Insertion Guide Tip Shape: Round
Insertion Guide Tip Type: Tapered
Insertion Guide Specifications: Not Provided
Mounting Side Shape: Straight (Press-Fit)
Surface Treatment: Not Provided
Heat Treatment: Directly Quenching
Steel Type: [SUJ2] SUJ2 Equivalent
Locating Side Outer Dia. P (Ø)(mm): 3
Locating Side O.D. Tolerance: -0.01/-0.02
Mounting Side Outer Dia. D(Ø): 2
Mounting Side Tolerance: m6
RM 7.90
Quantity:
/ EA
Stock:
93 EA in stock
In Seller's Warehouse
Add to Cart
Add To Shopping List
