Rs Pro 453909 15 Way Panel Mount D-sub Connector Socket, 2.77mm Pitch
Rs Pro 453909 15 Way Panel Mount D-sub Connector Socket, 2.77mm Pitch
Brand:
RS Pro
Model:
453909
Technical Data Sheets
Specifications
infotip-icon
View other D Sub Connectors dimensions or variations
Please select at least one specification below.
Length
23.5 mm
Pitch
2.77 mm
Current Rating
3 A
Mounting Type
Panel Mount
Depth
7.57 mm
Voltage Rating
250 V dc
Dimensions
23.5 x 10.64 x 7.57 mm
Gender
Female
Termination Method
Solder
Body Orientation
Straight
Contact Plating
Gold
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
+135°C
Number of Contacts
15
D Connector Type
Micro-D
Housing Material
Aluminium
Contact Material
Copper Alloy
Contact Size
0.127 μ
